WS-630H High Speed Scrap Metal Shear with 1400mm Blade 5-6 Cuts/min and PLC Control

  • WS-630H High Speed Scrap Metal Shear with 1400mm Blade 5-6 Cuts/min and PLC Control
Herkunftsort Jiangsu, China
Markenname DLK
Zertifizierung CE, ISO 9001
Modellnummer WS-630H
Min Bestellmenge 1 Satz
Preis USD 85000-95000 per Set
Verpackung Informationen Kunststofffolienverpackung mit Stahlrahmen, Containertransport
Lieferzeit 25-35 Werktage
Zahlungsbedingungen L/C, T/T
Versorgungsmaterial-Fähigkeit 10 Sätze pro Monat
Produktdetails
Modell WS-630H Maximale Schnittkraft 630 Tonnen
Klingenlänge 1400 mm Scherhöhe 300/420 Millimeter
Schnittgeschwindigkeit 5 bis 6 Mal/min Verarbeitungskapazität 12-18 Tonnen/Stunde
Gesamtleistung 132 KW Pumpentyp A4V250 x 2 Dual unabhängig
Kontrollsystem PLC + Fernbedienung Kühlung Dual Forced Air 52P x 2
Hervorheben

Dual Pump High Speed Shear

,

1400mm Blade Scrap Cutter

,

PLC Container Metal Shear
Hinterlass eine Nachricht
Produkt-Beschreibung
WS-630H High Speed Scrap Metal Shear 1400mm Blade Dual Pump 5-6 Cuts/min PLC Control Container Type
WS-630H High Speed Dual Pump Scrap Metal Shear

The WS-630H is an advanced high-speed container type scrap metal shear equipped with a dual independent pump hydraulic system, delivering up to 5-6 cutting cycles per minute — double the speed of conventional models. Designed for high-volume scrap processing yards and steel recycling facilities, this machine maximizes throughput while maintaining precise cutting control.

Key Features
  • Dual Independent Pump System: Two A4V250 pumps working in parallel for faster oil delivery and reduced cycle time
  • High-Speed Cutting: 5-6 cuts per minute vs. typical 2-3, significantly boosting daily processing capacity
  • Reinforced Blade Design: 4-edge reversible 1400mm blades made of Cr12MoV alloy steel with heat treatment
  • PLC Auto Control: Touch screen interface with remote control capability for unmanned operation
  • Enhanced Cooling: Dual forced air coolers (52P x 2) for sustained high-speed operation without overheating
  • Container Design: Roll-on/roll-off system for flexible yard-to-yard transportation
Applications

Suitable for cold shearing of round steel, square steel, channel steel, I-beam, steel plates, pipes, and various scrap metal structural parts in large-scale recycling facilities.

Technical Specifications
Parameter Specification
Model WS-630H
Max Cutting Force 630 Tons
Blade Length 1400 mm
Shear Height 300/420 mm
Cutting Speed 5-6 times/min
Processing Capacity 12-18 tons/hour
Total Power 132 KW (66 KW x 2 Motors)
Pump Configuration A4V250 x 2 (Dual Independent)
Hydraulic System Pressure ≤ 31.5 MPa
Control System PLC + Remote Control
Cooling System Dual Forced Air Cooler (52P x 2)
Power Supply 380V/3P 50Hz (Customizable)
Blade Material Cr12MoV Alloy Steel
Machine Weight 38 Tons
Our Service
  • 24/7 online technical support
  • One year warranty with lifelong maintenance
  • Free spare parts for quality issues within warranty
  • On-site installation and training available
  • OEM & ODM services available upon request

Contact us today for a customized quote and technical consultation.
