WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing

  • WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing
Herkunftsort Jiangsu, China
Markenname DLK
Zertifizierung CE, ISO 9001
Modellnummer WS-1000G
Min Bestellmenge 1 Satz
Preis USD 185000-215000 per Set
Verpackung Informationen Stahlrahmen mit Schutzverpackung, Container- oder Flat-Rack-Transport
Lieferzeit 45-60 Arbeitstage
Zahlungsbedingungen L/C, T/T
Versorgungsmaterial-Fähigkeit 5 Sätze pro Monat
Produktdetails
Modell WS-1000G Strukturtyp Leitungsrahmen
Maximale Schnittkraft 1000 Tonnen Klingenlänge 2100 mm
Scherhöhe 420/500 Millimeter Max Stahlplatte 80 mm Dicke
Max Rundstahl Φ150 mm Gesamtleistung 275 Kilowatt
Kontrollsystem SPS-Touchscreen + Fernbedienung Kühlung Wasserkühlrohrsystem
Hervorheben

Gantry Frame Metal Shear

,

2100mm Heavy Duty Cutter

,

1000 Ton Scrap Processor
Hinterlass eine Nachricht
Produkt-Beschreibung
WS-1000G Gantry Heavy Duty Scrap Metal Shear 2100mm Blade 1000 Ton Cutting Force Steel Plate Processing
WS-1000G Gantry Type Heavy Duty Scrap Metal Shear

The WS-1000G represents a departure from conventional container-type shears, featuring a robust gantry frame structure engineered for extreme-duty scrap processing. With 1000 tons of cutting force and a massive 2100mm blade, this machine handles oversized scrap that standard shears cannot process — including heavy structural steel, railway tracks, thick ship plates, and industrial machinery remnants.

Key Advantages of Gantry Design
  • Superior Structural Rigidity: Heavy steel gantry frame withstands extreme lateral forces without deformation
  • 2100mm Extended Blade: 30% longer than standard container models for processing oversized materials
  • 1000 Ton Cutting Force: Capable of shearing steel plates up to 80mm thick and round steel up to Φ150mm
  • Large Feed Opening: 3500mm x 2500mm hopper accommodates bulky scrap without pre-processing
  • Twin Shear Cylinder Design: YG500/320 cylinders with 5000kN x 2 force for balanced cutting
  • Industrial Grade Hydraulics: Heavy-duty Rexroth-type variable displacement pumps for continuous operation
Applications

Designed for heavy industrial applications including ship dismantling yards, large-scale steel mills, railway scrap processing, bridge demolition recycling, and heavy machinery disposal facilities.

Technical Specifications
Parameter Specification
Model WS-1000G
Structure Type Gantry Frame
Max Cutting Force 1000 Tons
Blade Length 2100 mm
Shear Height 420/500 mm
Cutting Speed 2-3 times/min (load)
Processing Capacity 15-25 tons/hour
Total Power 275 KW
Shear Cylinder YG500/320 x 2 (5000kN each)
Press Cylinder YG320/250 (2000kN)
Max Steel Plate Thickness 80 mm
Max Round Steel Diameter Φ150 mm
Feed Opening 3500 x 2500 mm
Hydraulic System Pressure ≤ 31.5 MPa
Control System PLC Touch Screen + Remote Control
Cooling System Water Cooling with Tube Cooler
Power Supply 380V/3P 50Hz (Customizable)
Machine Weight 68 Tons
Overall Dimensions 15000 x 3500 x 4200 mm
Our Service
  • 24/7 online technical support with remote diagnostics
  • One year comprehensive warranty with lifelong maintenance
  • Free spare parts for manufacturing defects within warranty
  • On-site installation, commissioning, and operator training available
  • Custom engineering solutions for specific scrap processing requirements

Contact our engineering team for a detailed proposal and site assessment.
